Applications:
Widely used for factory smelting processes, diesel burners, vaporizing furnaces, and integrated kitchen ventilation. Particularly well suited for blower supply on boiler systems, plastics and chemical production, drying equipment, film-blowing machines, printing presses, and textile machinery.
| Core Technical Parameters | |||||||
| Model | Power (W) |
Voltage (V) |
Frequency (Hz) |
Air flow (m³/h) |
Total pressure (Pa) |
Rotation speed (rpm) |
Caliber (mm) |
| TZY-6367 | 250W | 220 | 50 | 720 | 1300 | 2800 | 63 |
| TZY-6368 | 370W | 220 | 50 | 780 | 1400 | 2800 | 63 |
| TZY-7666 | 550W | 220/380 | 50 | 900 | 1700 | 2800 | 76 |
| TZY-7667 | 750W | 220/380 | 50 | 1020 | 1900 | 2800 | 76 |
| TZY-9666 | 1100W | 220/380 | 50 | 1260 | 2300 | 2800 | 96 |
| External Dimensions | |||||||||
| Model | Power (W) |
External Dimensions
(mm) |
|||||||
| M | N | L | Φ1 | Φ2 | Φ3 | Φ4 | a*n | ||
| TZY-6367 | 250W | 380 | 350 | 210 | 65 | 95 | 115 | 110 | 4*10 |
| TZY-6368 | 370W | 380 | 350 | 360 | 65 | 95 | 115 | 110 | 4*10 |
| TZY-7666 | 550W | 440 | 420 | 230 | 70 | 100 | 125 | 120 | 4*10 |
| TZY-7667 | 750W | 450 | 410 | 320 | 70 | 100 | 125 | 120 | 4*10 |
| TZY-9666 | 1100W | 490 | 440 | 340 | 85 | 130 | 150 | 175 | 4*10 |
The CBF Explosion-Proof Axial Fan is specialized ventilation equipment for hazardous environments. The fan is composed of an explosion-proof motor, blades, casing, etc. To prevent sparks from friction, the blades are made of cast aluminum alloy.The fan features low noise, low energy consumption, and superior performance. In addition to ventilation and exhaust, it can be installed in spaced series along long exhaust ducts to increase duct pressure. Unlike general fans in structure and material, its applications are similar.
The SFA premium axial flow fan improves upon the SF model by redesigning the blades and adopting an aluminum alloy casing to enhance the motor’s sealing performance. It features low noise, large air volume, high wind pressure, excellent heat dissipation, and stable operation.
Ideal for moisture-proof drying; localized heating; construction sites; outdoor heating; equipment insulation; railway stations and airports; yachts and ships; paint drying; mobile heating; quick warming; venues and clubs; clean heat delivery; rapid temperature rise, etc. Working pressure ≤ 0.8 MPa.
The SFB high-air-volume axial flow fan has undergone comprehensive upgrades based on the SF model, equipped with aluminum alloy sickle-shaped blades. It adopts an aluminum alloy casing to enhance the motor’s sealing performance, featuring low noise, large air volume, high wind pressure, excellent heat dissipation, and stable operation.
The vortex air pump has the characteristics of compact structure, small volume, light weight, low noise, and dual-use of blowing and suction. The shell is made of aluminum alloy material, further optimizing heat dissipation, and the motor is wound with pure copper wire . Widely used in supporting equipment, water treatment aeration, aquaculture, gas transmission, air dust removal, dry bottle, feeding, collection, etc.
The fan features high wind pressure, high rotation speed, large air volume, mobile convenience, and strong suction. The casing is made of cold-rolled steel with plastic spraying, the impeller is cast aluminum alloy, and the motor is wound with pure copper wire. Manufactured with optimized aerodynamic design and advanced processing technology, it has a lighter structure.
The Y5-48 series boiler centrifugal induced draft fan is specially designed to support industrial boilers (1-20 t/h) fired with various coal types and equipped with smoke and dust removal devices. It can be selected for any applications with similar inlet conditions and compatible performance requirements. The maximum ambient temperature for the fan operation shall not exceed 250°C, and the medium handled is flue gas. A dust removal device must be installed ahead of the induced draft fan to ensure the dust concentration in the flue gas entering the fan is less than 400 mg/m³.
The T40 axial flow fan is suitable for ventilation and heat dissipation in general factories, warehouses, offices, and residences. Removing the casing allows it to be used as a free-standing fan, or it can be installed in spaced series along long exhaust ducts to increase air pressure in the pipeline. According to user needs, this series can adopt an external motor (mounted on the casing) with belt drive in its structure, designated as model KT40. It shares the same performance parameters as the T40 fan, with the primary function of exhausting high-temperature or moisture-resistant gases.
The YW5-47 series boiler induced draft fan (air-cooled high-temperature resistant) is a new-type high-efficiency and low-noise boiler fan developed by our company specifically for the domestic boiler industry, based on referencing advanced foreign prototypes. This series of fans is currently one of the lowest-noise and minimal-vibration products in domestic boiler fans, reaching the advanced domestic level.
The HF series oblique flow pressurized pipeline fan is a new type of fan designed by our company.The casing is made of high-quality ABS engineering plastic, and the fan blades and flow channels are designed reasonably to effectively achieve the boosting effect. The air inlet and outlet can be connected to circular pipes of the same diameter, making installation simple and greatly saving pipeline design and installation costs. It has the advantages of large air volume, high pressure, low noise, low vibration, low power consumption, long service life, small size, light weight, and stable operation. This fan compensates for the insufficient static pressure of axial flow fans. It can effectively regulate air, removing moisture, dust, odors, and purifying the air to keep the indoor environment fresh.
NCF-A high-pressure low-noise cabinet-type smoke exhaust fan is a cabinet-type smoke exhaust fan designed by our company in response to the ever-evolving commercial kitchen environments.The pressure of this fan is higher than that of a general box-type fan of the same power, while the air volume is greater than that of a general centrifugal fan.
The HX63 is a new type developed from the 11-62 series. Engineered to meet the demands of green industry and environmental noise reduction. Featuring a redesigned impeller with an optimized aerodynamic blade structure. This delivers key advantages: low noise, minimal vibration, and extended service life. Suitable for kitchen exhaust, fume extraction, or ventilation in public venues like canteens, hotels, and restaurants. Also ideal for use with production equipment such as grain machinery, chemical machinery, and plastic machinery. Highly versatile and adaptable for wide-ranging applications.
The T35-11 series axial flow fans are suitable for transporting non-corrosive gases free of significant dust, with the ambient temperature not exceeding 60°C.It is widely used for ventilation and cooling in ordinary factories, warehouses, offices, and residential buildings.
The stove fan can be installed in the stove system to enhance air circulation or exhaust smoke. It is commonly found in household stoves, integrated stoves or commercial kitchen equipment.
The BFAG explosion-proof exhaust fan is a commonly used explosion-proof ventilation device in the industrial field. It is mainly used in environments containing flammable and explosive gases or dust to ensure that the equipment does not ca use fire or explosion during operation.
Applications: Suitable for moisture-proof drying, localized heating, construction sites, outdoor heating, equipment insulation, railway stations and airports, yachts and ships, paint drying, mobile heating, convenient warming, venues and clubs, clean heat delivery, rapid temperature rise, etc. Working pressure ≤ 0.8 MPa.
