The YW5-47 series boiler induced draft fan (air-cooled high-temperature resistant) is a new-type high-efficiency and low-noise boiler fan developed by our company specifically for the domestic boiler industry, based on referencing advanced foreign prototypes. This series of fans is currently one of the lowest-noise and minimal-vibration products in domestic boiler fans, reaching the advanced domestic level.
The YW5-47 series boiler induced draft fan (air-cooled high-temperature resistant) is a new-type high-efficiency and low-noise boiler fan developed by our company specifically for the domestic boiler industry, based on referencing advanced foreign prototypes. This series of fans is currently one of the lowest-noise and minimal-vibration products in domestic boiler fans, reaching the advanced domestic level.
The fan is equipped with Y2 series high-temperature resistant motors made of aluminum alloy by die-casting, and uses a thermal-insulated connecting base (with built-in cooling vanes) to connect the motor and fan casing, ensuring the motor operates normally in high-temperature environments. The fan casing is made of thickened high-quality steel plate, cut by laser, with an operating temperature range of 150-220°C.
It is widely applied in heating furnaces, hot-blast stoves, CNC boilers, steam boilers, drying, chemical, food, grain machinery, and other related industries.
| Core Technical Parameters | ||||
| Power (kW) |
Voltage (V) |
Rotation speed (r/min) |
Air flow (m³/h) |
Total Pressure (Pa) |
| 0.12kW | 220v/380v | 2800 | 310-500 | 450-370 |
| 0.18kW | 220v/380v | 2800 | 350-650 | 520-400 |
| 0.25kW | 220v/380v | 2800 | 410-900 | 600-470 |
| 0.37kW | 220v/380v | 2800 | 520-1150 | 700-550 |
| 0.55kW | 220v/380v | 2800 | 680-1450 | 880-680 |
| 0.75kW | 220v/380v | 2800 | 880-1850 | 1050-790 |
| 1.1kW | 220v/380v | 2800 | 1250-2300 | 1240-940 |
| 1.5kW | 220v/380v | 2800 | 1400-2800 | 1350-1140 |
| 2.2kW | 220v/380v | 2800 | 1800-3100 | 1830-1280 |
| 3kW | 220v/380v | 2800 | 2500-3600 | 2520-1500 |
| 4kW | 380v | 2800 | 3100 | 2900 |
| 5.5kW | 380v | 2800 | 3680 | 3200 |
| Model | L | W | H | D | d | A | B |
| YW5-47-0.12kw | 330 | 315 | 270 | 135 | 110 | 114 | 65 |
| YW5-47-0.18kw | 330 | 315 | 270 | 135 | 110 | 114 | 65 |
| YW5-47-0.25kw | 370 | 360 | 330 | 180 | 135 | 120 | 65 |
| YW5-47-0.37kw | 380 | 370 | 310 | 180 | 130 | 120 | 80 |
| YW5-47-0.55kw | 430 | 415 | 365 | 200 | 150 | 140 | 90 |
| YW5-47-0.75kw | 430 | 415 | 365 | 200 | 150 | 140 | 105 |
